- Size: 30m3
- Place of Origin: SHANDONG
- Brand Name: LONGYE
- Model Number: SLY500
- Weight: 6700.000 kg
SLY500 track-type water well drilling rig is lightweight, efficient, multi-purpose drilling equipment, which can use air, foam or mud rotary for percussive drilling according to different textures. It is widely used in industrial and agricultural water conservancy projects, such as drilling wells, testing wells or other exploration boreholes, in particular, in drilling hole for geothermal heating it can also meet the engineering basis for reinforcement, loose gravel drilling rock formation connected with a variety of engineering requirements.
Main technical parameters
Bore diameter（mm） | 115-350 |
Bore depth（m） | 213 |
Walk speed（km/h） | 0-2.5 |
For rock | F=6-20 |
Air pressure（Mpa） | 1.05-3.0 |
Air consumption(m3/min) | 16-30 |
Once promotion（mm） | 3000 |
Skid max angle(。) | 90 |
Maximum height from the ground（mm） | 320 |
Rotation Speed（r/min） | 0-100 |
Rotation torque（Nm） | 3900 |
Lifting power（T） | 8 |
Climb ability(。) | 25 |
Dimension（L*W*H)(mm) | 5300*2100*2700 |
weight(Kg) | 6700 |
